MCSH22-60 Computer winding machine

Machine Feature:
The machine with cabinet type design, with the cast iron body, stable and reliable quality, This machine design of 32 bit controller chip, It’ll be faster and higher reliability.In Chinese and English display,easy to operation,winding data retention after power failure, not to discarded products。All the parts for this machine are imported prats,such as:Japan Bearing (NSK、NTN),Japan BANDO belt ，Japan GATES belt ，Taiwan Ball screw (TBI)，Taiwan Transducers and so on.

Function and feature：
①.Using the latest synchronization with the coupling cable controller.
②.With self detection, including setting error, speed tracking and velocity calibration.
③.Optional lifting speed of main spindle.
④.Start moving speed of the spindle motor to climb time to decide.

Application range：
EE transformer,EI transformer,Stepping motor,Relay,coil class,auto ABS,Switch power transformer and special products.

Specifications：
Spindle number 6
Wire size range 0.05-0.45mm
Loop diameter 70mm
The max wire spacing 9.99mm
Winder width 60mm
Spindle pitch 85mm
Max speed 0-7000turn/min
Spindle motor Phase motor+AC Drives
Winder motor Stepping motor
Input power 220V  50HZ/60HZ
Machine size 920×780×950mm
Package size 990×740×1010mm
Net weight 120kg
Gross weight 150kg
