UNBOXING OF HMT MAKE SLANT BED COMPUTER NUMERIC CONTROL MACHINE || SBCNC 60

Designed for high speed turning of components, with high rigidity and minimum torsional deflection.
» The single machine for multiple benefits.
» Optional Turn Mill Center with C-axis and driven tools.
» Optional Flexible Turning Cell with gantry job/tool loading/unloading and post processor.
» 70° Inclined computer optimised slant bed with large torque tube.
» Separate pairs of hardened and ground rectangular guideways for saddle and tailstock.
» Main spindle supported on Gamet preloaded taper roller bearings.
» Large precision curvic couplings ensure accuracy of turret indexing and high rigidity of turret.



Specifications :
SBCNC 40 SBCNC 60
Swing over bed mm 660 800
Maximum turning dia. mm 400 600
Maximum turning length mm 1250/2000/3000 1250/2000/3000
Maximum chuck dia. mm 500 600
Bar passage mm 103 (210 optional) 103 (210 optional)
Spindle power kW 22 (up to 60) 22 (up to 60)
Speed range rpm 12-2800 12-2000
Rapid traverse m/min 10 10
No. of tool stations m/min 12 12
Tailstock quill travel mm 125 / 160 125 / 160
Control system Siemens / Fanuc Siemens / Fanuc
Maximum weight carrying capacity
Maximum turning length mm 1000 1000
Maximum chuck dia. mm 1500 1500
Bar passage mm 500 500
