SRF212-4 Four Spindle Rotor Winding Machine

The machine adopts Taiwan PLC touch screen, AC servo motors, all in English and Chinese display control. Selection of Japan Bearing (NSK / NTN), Japan BANDO belt, USA GAICI belt, Taiwan ball screw (TBI) and guide rail and other imported parts. High speed , precision accurate, Let the customer in the process of using experience to the effects of time and high production.

Function and feature：
1.Automatic winding, change groove, and shearing thread end of wire.
2.Can improve production , reduce wire losses, Improve product quality.

Application range：
All kinds of outer micro motor ,rotor .

Specifications：
Spindle number 4
Wire size range 0.05-0.4mm
Winding Accuracy ±0.1°
Cable Accuracy ±0.01mm
Corner Accuracy ±0.1°
Air Pressure 4-6kg²/cm
Max speed 6000 turn/ min
Spindle motor 1HP Servo Motor
Winder motor Stepping motor
Corner Motor 200W Servo Motor
Input power 220V 50HZ/60HZ
Dimensions 1220*780*1260mm
Net weight 160kg
The company based on the principle of product innovation, reserves the right to change the product materials, specifications and design are subject to change without notice.
