Fiber Orientation Visualization in UHPFR Concrete using Avizo Fire

Hosted by Dailymotion. For legal issues report at the Copyright Center, report us on DMC, or use the Instant Removal tool.

Fiber Orientation Visualization in UHPFR Concrete using Avizo Fire

F
FEI Visualization Sciences Group

1 Views • Nov 21, 2012

Description

Related paper available on http://www.vsg3d.com/scientific_communications.
A sneak peek video of a new study on "Fiber orientation visualization and analysis" that was prepared for and presented at the Conference on Industrial Computed Tomography (ICT) 2012 (Wels, Austria / Sept 19-21, 2012).

The application of fiber orientation, visualization, fiber orientation simplification, and its evaluation were applied on an Ultra-High Performance Fiber Reinforced Concrete (UHPFRC) which is used for the on-site repair of bridges in Slovenia.
The image processing, fiber separation, orientation calculation, and visualization have been done by using Avizo Fire 3D analysis software.

A study by P. Westenberger, P. Estrade, D. Lichau
VSG | Visualization Sciences Group
an FEI Company

Data © Dr. Alenka Mauko and Dr. Aljosa Sajna - Slovenian National Building and Civil Engineering Institute - ZAG
