Notching Machine Schnell

Servo controlled precision Notching machine for motor lamination manufacturing.

Main features & benefits:
One piece heavy duty rigid cast frame made out of high grade cast iron to give stability and improved vibration damping.
Compact dimensions of the machine
Notching speed can be set on the screen
Number of slots can be set on the screen
Slide position w.r.t. the center of the indexing spindle
Angular position for the cycle start
Blank centering adjustment
Speed reduction at the end of the notching cycle
Machining cycles can be stored and recalled
Activation of special machining cycles such as skip (conical & skew optional).
Alarms & diagnostic
Direct drive servo indexer reduces maintenance and improves accuracy in Model No. SNM-20 & SNM-30.
In SNM-30 model notching of rotor and stator in one clamping
HMI with touch screen (size as per customer requirement)
Automated loading and unloading(optional)
Top clamp assembly automatically move w.r.t. indexing table
Automatic top clamp and ejector assembly
Centralized machine lubrication system
