Linear Motion Table (motorized)

Ensures 100 mm travel range linear motion with 0.125 µm resolution.
8MT167-100 translation stage manufacturer specifications: http://www.standa.lt/products/catalog/motorised_positioners?item=64

Main Features:

Travel range: 100 mm
Resolution 1/8 step: 0.125 µm
Lead screw pitch: 0.5 mm
Reduction motor/screw 2.5:1
Bi-direction repeatability*: 2 µm
Maximum speed: 5 mm/s
Maximum load:
Horizontal 7 kg
Vertical 3 kg
Mechanical end limit switches 2, Pushed is "closed"
Full step division to 256 microsteps with Standa controller
Multi-axis configurations available.
