How to build a simple Arduino on a breadboard || Arduino tutorial

In this video Im demonstrating how to build a simple Arduino on a breadboard, based on Atmel Atmega8/168/328 microcontroller.\r
When I build my Arduino projects usually I dont need the whole Arduino board and all of its functionality. In many cases I use only basic input and output pins and thats why I assemble a simplified version of Arduino.\r
\r
When connecting your Arduino to a power supply or a battery make sure that you connect the red jumper wire to the positive terminal and the blue one to the GND. There is no protection against reversed polarity and you may blow something up.\r
\r
The circuit diagram for this project is available on my website:\r
\r
\r
My build is based on:\r
\r
\r
If you want to know how to program a simple Arduino on a breadboard go to:\r
\r
\r
See all my Arduino tutorials here:\r
\r
\r
Subscribe to get notified about my new videos:\r
\r
