Gain Phase Response

C
Cleverscope

22 Views • Dec 05, 2012

Description

Use Cleverscope to measure the Gain Phase response of a network. Results are displayed in linear or log form, with linear or log frequency axis. Phase can be displayed in radians or degrees, and unwrapped to achieve a continuous plot. The internal 0-10 MHz sig gen, or an external sig gen can be used.

Keywords & Tags

#cleverscope #usb oscilloscope #spectrum analyser #protocol analyser #mixed signal oscilloscope #cs328a #gain phase #bode plot
