cosmetic/eye bottle/container screen printer

Website: www.wwprinter.com
http://www.wwprinter.com/Auto-One-Color-Screen-Printer-Machine-ASP-M1-20.htm
Email: printersale@126.com
The auto bottle screen printer can print eye dropper, container, plastic bottles etc.
Auto Container Screen Printer Machine ASPM1 is fit for round, flat and oval container printing.
For example: shampoo bottle, baby feeder, perfume bottle etc.

Parameters:

1:Max.Printing size: Round Container :(φ25X100mm)x(60-280mm)　
Oval Container: (40-120mm)Width x (60-280mm)Height
2:Speed(Pieces/minute): Round Container : 60　
Oval Container: 75
3:Machine size(LxWxH): 194X140X160cm
4:Net Weight: 1200kg　　
5:Air Pressure(bar): 5-7　
6:Power: 380V/3P 50Hz 7kw

Features:

Cam-linkage mechanisms driving mode combined with PLC control system effectively guaranteeing the
reliability and efficiency.

Main components from Rexroth,Schneider,SMC, Mitsubishi etc.Other parts machined in-house by CNC
directly from CAD.

Frame & structures made by high intensity aluminum alloy and stainless steel.

Easy operation with PLC control system, touch screen interface.

Fast setup & quick tooling change over.

Adopted with No-object no printing system, auto counter, faulty alarm device.

Options:
General unit for round & oval bottles, antistatic device, flame treatment, UV/IR system, auto trimmer
system and other customizations due to order.
