Cantilever rotocone vacuum dryer

Rotocone Vacuum Dryer
ROTOCONE VACUUM DRYER, to some extent, replacing the agitated rotary Vacuum Dryer. It has two opposing jacketed cones on a common jacketed short cylindrical base.When the cones are in a vertical position the dryer can be rapidly discharged.The unit is provided with supporting trunnions running on suitable bearings. The trunnions are allowing. A vacuum Connection is made through one of the trunnions.The connection pipe is turned upwards in the cone and is fitted with a dust filter at its end. Inlet and outlet pipes pass through the outer trunnion for the supply of suitable heating medium to the jacket. A special design of a rotating valve is used for this purpose. One of the trunnions is driven through a reduction.gear and chain drive.Rotation speed will range from 12 rpm for small units to large commercial installations. The Horsepower is varied between 0.5 and 15. The base cylinder diameter is about 1 m to 3m.

Capacities:

Standard Two design: 10 litres to 5000 litre
Cantilever design: 10 litres to 2000 litre

Material of construction:

Stainless Steel, Mild Steel, Carbon Steel, Halar Coating, Rubber Lining, Hastelloy cladding, Teflon lining.

Features:

Low drying temperature, fast drying
Uniform drying
Easy to clean internal surface
