Automatic Screen Printing Machine for Caps Side Wall

http://www.printer-manufacture.com/Automatic-Screen-Printing-Machine-for-Bottle-Caps-p515.html

This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc .
Advantages:
1 Automatic single color screen printer on Bottle caps;
2 High efficiency, Auto Feeding, Flame Treatment , Auto Loading and Screen printing as well as UV drying all in one function.
3 Online Flame Treatment.
4 Reliable PLC control & touch screen operation system.
5 Closed working system, well safety protection:
6 Promise of quality with SMC, FESTO pneumatic parts and Omron, Siemens Electric parts.
7 High quality aluminium alloy ensure light and ruggedization
Specification
1.Printing speed: 4000-5000Pcs/hr
2.Printing diameter:Round Dia φ15~φ60mm
3.Printing objects length: 20~200mm
4.Compress air:0.6~0.8MPa:
5.Burning oil air: 0.15MPa
6.Main machine dimension: 260*160*280CM
7.Power: 3KW,220V
8.Packing Size: 2 Wooden Case
1)Wooden Case Size:150*115*193CM(Main Part)
2)Wooden Case Size:270*125*120CM(Upload System)
