Automatic High Speed Bottle Unscrambler

V
VKPAK Machinery

5 Views • Mar 14, 2023

Description

Automatic Bottle Unscrambler is making up of bottle elevator, round plate, bottle rejector, bottle-arranging and the electrical cabinet. Put disordered bottles to the bottle elevator, through round plate, conveying belts, bottle arranging parts, then bottles can stand on the belts. This machine is characterized by the compact structure, simple operation principle, mature technique and stable movement.

https://www.vkpak.com/automatic-high-speed-bottle-unscrambler.html

Specifications

1. Applicable Bottle Diameter: Φ45-90mm;
2. Applicable Bottle Height: 80-240mm;
3. Speed: ≤200bottle/min;
4. Air Pressure: 0.5~0.7 MPa;
5. Power: 2 KW;
6. Power Source: AC220V, 50Hz;
7. Bottle-Elevator Dimension: 2200*1000*1900(L×W×H) mm;
8. Unscrambler Dimension: 2600*1450*1370(L×W×H) mm;
9. Weight: About 1250Kg;
