#1 PLC serial control
5 Views • Aug 16, 2017
Description
Siemens S7 315-2DP
Siemens CP340 (For the serial communication)
Siemens ET200M connected to S7 315 through profibus
Siemens SM322 output module
16 channel relay board wired with the SM322
Advantech PCI card 1750 wired with the relay board
The software used:
Factory IO
Step7 Classic
Programming languages used:
PLC program and serial framework written in SCL.
Application for the communication between Factory IO and Advantech card written in C#.
