0002. Internal Geneva mechanism 5

Input: pink crank.
Output: yellow shaft of Geneva disk.
Angle of each rotation of the driven shaft is 90 degrees.
The ratio of dwell period to motion period of the output is K = 1/1.
In conventional internal Geneva drive K = 1/3
Violet sector and orange disk are for keeping the output immobile when red roller does not contact the Geneva disk.
Green curve is locus of the roller center.
This video was made based on:
