It is estimated that on average, each airplane in the U.S. commercial fleet is struck lightly by lightning more than once each year. In fact, aircraft often trigger lightning when flying through a heavily charged region of a cloud. In these instances, the lightning flash originates at the airplane and extends away in opposite directions. Although record keeping is poor, smaller business and private airplanes are thought to be struck less frequently because of their small size and because they often can avoid weather that is conducive to lightning strikes.

The last confirmed commercial plane crash in the U.S. directly attributed to lightning occurred in 1967, when lightning caused a catastrophic fuel tank explosion. Since then, much has been learned about how lightning can affect airplanes. As a result, protection techniques have improved. Today, airplanes receive a rigorous set of lightning certification tests to verify the safety of their designs.

Although passengers and crew may see a flash and hear a loud noise if lightning strikes their plane, nothing serious should happen because of the careful lightning protection engineered into the aircraft and its sensitive components. Initially, the lightning will attach to an extremity such as the nose or wing tip. The airplane then flies through the lightning flash, which reattaches itself to the fuselage at other locations while the airplane is in the electric "circuit" between the cloud regions of opposite polarity. The current will travel through the conductive exterior skin and structures of the aircraft and exit off some other extremity, such as the tail. Pilots occasionally report temporary flickering of lights or short-lived interference with instruments.

Most aircraft skins consist primarily of aluminum, which conducts electricity very well. By making sure that no gaps exist in this conductive path, the engineer can assure that most of the lightning current will remain on the exterior of the aircraft. Some modern aircraft are made of advanced composite materials, which by themselves are significantly less conductive than aluminum. In this case, the composites contain an embedded layer of conductive fibers or screens designed to carry lightning currents.

Modern passenger jets have miles of wires and dozens of computers and other instruments that control everything from the engines to the passengers' headsets. These computers, like all computers, are sometimes susceptible to upset from power surges. So, in addition to safeguarding the aircraft's exterior, the lightning protection engineer must make sure that no damaging surges or transients can reach the sensitive equipment inside the aircraft.
