UV Drying Machine UV Conveyor Dryer

http://www.printer-manufacture.com/UV-Conveyor-Dryer-p635.html

EC-500UVF
1.Conveyer width：500mm
2.Total wattage：7KW
3.Wind fan wattage：500W/380V
4.Conveyer motor wattage：1000W/1P/380V
5.ConveyEr speed：0~10m/min
6.Speed adjustment：stepless
7. Outer dimension：2000×660×980mm(l×w×h)
8. Net weight：180KG Gross Weight: 220KG
9. Lamp wattage:3KW/380V×2pcs.
10.Package: 2160*840*1380mm;
Pack in Wooden Case/Poly Wood Case
EC-700UVF
1.Conveyer width：700mm
2.Total wattage：7KW/11.2KW
3.Wind fan wattage：500W/380V
4.Conveyer motor wattage：1000W/1P/380V
5.ConveyEr speed：0~10m/min
6.Speed adjustment：stepless
7. Outer dimension：2150mm*1020mm*1320mm(l×w×h)
8. Net weight：180KG Gross Weight: 220KG
9. Lamp wattage:3KW/380V×2pcs; 5.6KW/380V×2pcs(optional).
10.Package: 2160*980*1380mm;
Pack in Wooden Case/Poly Wood Case
EC-800UVF
1.Conveyer width：800mm
2.Total wattage：7KW 11.2KW
3.Wind fan wattage：500W/380V
4.Conveyer motor wattage：1000W/1P/380V
5.ConveyEr speed：0~10m/min
6.Speed adjustment：stepless
7. Outer dimension：2150*1100*1250mm(l×w×h)
8. Net weight：270KG Gross Weight: 365KG
9. Lamp wattage:3KW/380V×2pcs; 5.6KW/380V×2pcs(optional).
10.Polywood Case size: 2240*1180*1320mm;
EC-1000UVF
1.Conveyer width：1000mm
2.Total wattage：7KW/11.2KW
3.Wind fan wattage：500W/380V
4.Conveyer motor wattage：1000W/1P/380V
5.ConveyEr speed：0~10m/min
6.Speed adjustment：stepless
7. Outer dimension：2000×660×980mm(l×w×h)
8. Net weight：300KG Gross Weight: 400KG
9. Lamp wattage:3KW/380V×2pcs; 5.6KW/380V×2pcs(optional).
10.Package: 2240*1350*1380mm;
Pack in Wooden Case/Poly Wood Case
Advantages:
1. Made by high temperature conveyer belt,
2. Famous brand motor drive,stepless speed adjustment.
3. High quality UV lamp to ensure exposure power.
4. Taiwan transformer,startup organ . long life to use
5. With convulsions function to remove quantity of heat in curing case.
Product Description:
Drying for variety of UV screen printing, pad printing, spraying UV ink processing, such as UV varnish, frosted, wrinkle, brilliant, refraction, enclosure spraying, single/double-sided green oil, offset supporting
Application range:
Used to make crystal pattern,frosted crystalam,colourful pattern ,etc,specia in the golden and silver card,metal ,glass and plastic ,etc,As well as,matched with offset printing for the UV drying of the offset printing ink.
