Scorpio LK Solution # Part 2/2

Scorpio LK Solution with TANGO device
for programming of transponders, that are a part of automobile immobilizing systems.

Unlike the previous model the Gambit, new model Tango is the two-band device that has allowed to add the list supported transponders with firm Texas Instruments products (Tiris ©).

The list of supported for the present moment transponders.

Philips transponders:
PCF7930-31 writing, reading
PCF7935 writing, reading, shadow memory, crypto calculator
PCF7936 writing, reading, modes password, crypto, Manchester & Biphase encodings
PCF7941 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7942 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7943 transponder, remote, Manchester & Biphase encodings
PCF7944 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7945 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7945AC (VAG 2010-) IDE, eeprom reading
PCF7946 transponder, remote, Manchester & Biphase encodings
PCF7947 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7952 transponder, remote, eeprom, Manchester & Biphase encodings
PCF7953 IDE, eeprom reading
PCF7961 transponder, remote, Manchester & Biphase encodings
*Auto switching between PCF7936 … PCF7961 windows if invalid type detected.
*Autodetect manchester / biphase

Temic transponders:
Temic 11 reading , writing to T5, TK5551
Temic 12 reading , writing to T5, TK5551
Temic 8C reading

Megamos transponders:
Megamos (13) reading , writing to T5 , emulating on PCF7930-35
Megamos (48) reading, writing, PIN, unlock by PIN,
full range of memory contents, crypto calculation
Megamos CRYPTO-2 (8E) read ID, read/write EEPROM, write Cryptokey

Texas transponders:
Tiris (4C) reading
Tiris (4D) DST crypto reading, writing, crypto calculator
Tiris (4E) DST crypto reading, writing, crypto calculator
Tiris (DST+) reading

Atmel:
TK5551M (T5 replacement)

SAAB reading , writing to T5

The product is in working out stages, therefore the list of the supported transponders will be developed later.
