Large Area Laser Engraving and Cutting Machine

Suitable for two-color panels, plexiglass, glass, bamboo, paper, rubber, marble, granite, tile and other non-metal materials.

Technical Parameter
Laser type Hermetic and detached CO2 laser tube
Laser power 80W（Standard collocation）or RF100W 150W（Select collocation）
Cutting area 1300mm×2500mm
Cutting table Strip panel working table
Cutting(no-load)speed 0-36000mm/min
Repeating location ≤0.07mm
Moving system Offline servo control system, synchro belt moving
Cooling system Constant temperature water chiller for laser machine
Power supply AC220V±5% / 50HZ
Format support AI、BMP、PLT、DXF、DST etc
Standard collocation Following top & bottom exhausted system, medium pressing exhaust device,550W exhaust fans, mini air compressor
Select collocation Laser process accessory box, CCD Camera positioning system, auto following focusing system, automatic control high pressure blower valve
