Install Sealed Ink Cup for Pad Printer

Single Color Sealed Cup Pad Printer

http://www.printer-manufacture.com/Single-Color-Sealed-Cup-Pad-Printer-p359.html

Product Information：
This machine is sealed ink cup printing machine based on sliding mode conversion cup of ink, increase
ink cup trip for a long number printed pattern designed products. If the printed pattern longer, then scraping
scraper will not clean, so this machine uses ink scraper cup ink, the ink is not clean to avoid scratching and
other issues.
It is suitable for electronic, plastics, toys and other products for monochrome printing machinery, such
as cell phone button, golf ball, toys, pens, mouse, electronic products, handicrafts, etc., for a variety of
printed materials For example: metal, glass, ceramics, plastics and so on. Printing area is relatively small
plane, and the irregular surface of the product arc printing.
Sealed Ink Cup Pad Printer with the latest nano-technology ink cup made of tungsten steel cutting ring,
the surface hardness up to HRC63 degree, with high wear resistance, can withstand nearly 300 million
times the friction that this section of the machine than the traditional ink tray machines moreenvironmentally
friendly and more fuel efficient.
Feature:
·Advanced computerized system control
·pneumatically driven adopt from FESTO, can adjust the movement speed of each part
·Built-in LED digital counter
·Emergency stop system to ensure the safety of operator
·Light-weight, strong aluminum cast machine frame
·Ink trays, work table and pads are independently adjustable for easy color registration
·Speed, pad and printing stroke are easily adjustable for different printing requirements
·Ink tray, doctor blade, brush and pads are easily installed and dismounted for quick cleaning
·The ink cup promote by cylinder ,can be slide more smoothly
Specifications：
Operation：Semi-Automatic
No. of color：1 color (can be color-process)
Working station：1Pcs
Work table size: 400x125mm
Standard plate size:100x500mm(4"*20")
Ink cup diameter: 60-90mm(optional)
printing speed :1600Pcs/Hour
power :220V 50Hz
pressure: 6Bar
