Improved Color Organ & Non-Linear Bargraph

T
threeneurons

11 Views • May 21, 2015

Description

Demonstration of color organ circuit, based on proper phase versus amplitude relationship. Better dynamic range than older "statistical" (crap shoot) circuits. Also an IN-13 VU meter, which uses piece-wise linearization, to make a non-linear dB scale.

Keywords & Tags

#Neon #Color Organ #Nixie #Non-Linear Circuit
