How to Use Location Wall Properties in Revit - Modeling Features - 03
3 views • Jun 02, 2025
Description
Location wall properties allow you to control the positioning and orientation of walls. To access and use these properties:
Select the wall.
Go to the "Properties" palette.
Adjust properties like:
- Location Line (e.g., Wall Centerline, Finish Face).
- Base and top constraints.
- Offset and orientation.
By modifying these properties, you can precisely control wall placement and relationships in your Revit project.
