HAND OPERATED PASTE FILLING MACHINE.

for further inquiry call us on +91 9867170371 or visit our website : www.printopackmachines.com or write us on [email protected]

Description :

This is the basic and proved machine for paste or tube filling Industry. Very widely used and famous among small and medium production industry. Hand Operated Paste Filling Machine is very economical, easy to operate and easy to maintain type. Any semi-liquids and pasty materials, like cream, pastes, gel, ketchup, and other same kind materials can be easily filled accurately by using this machine.
Machine Structure and Working:
Machine base and main structure is made from Cast steel which is machined and duly powder coated to get the finish. There are parts like hopper and operating lever , fill barrel, nozzle, and adjustment screw are present in all machines.
There is a strong Hopper provided with required volume capacity as per material. Small models comes with moving hopper and bigger models comes with steady Hopper. The Hopper is made from Stainless steel 304 as per specification.
Fill Barrel is another main part in this machine. This is also made from Stainless steel. The inside of each barrel is ground to get mirror finish. Barrel design is done as per fill volume requirements. The barrels are available in 15gms, 25gms, 50gms, 100gms, 150gms, 250gms. The piston is a specially designed one, which does suction and filling in one stroke. Fill nozzles are welded to the barrel. The mouth of nozzle is maintained towards down to fill smoothly into containers or tubes below the fill barrel.
Special Features:
• Steady hopper provided for Fill easiness(Hopper will be steady and handle only moves during filling)
• Volume adjustment made easily by set screw
• Jacketed hopper available on request
• GMP models available with us
• Any volume sizes from 5gms. To 500gms. Barrel is available as per requirement

Specifications;
1. Machine Model: AEHPF100
2. Machine type: Hand operated Paste Filling Machine
3. Machine dimensions: 8" W X 10" B X 24" L
4. Hopper Capacity: 15 Liters.
5. Machine weight: 28 kgs.
6. Packing Size: 10" X 12" X 25"H
7. Gross weight: 35 Kgs.
8. Packing: Wooden Box.
9. Fill range: 15gms-250gms per stroke.
10. Fill capacity: up to 20 fills per minute
