Glue Labeling Applicator Machine

http://www.printer-manufacture.com/Semi-Auto-Paste-Labeling-Machine-p535.html

http://www.printer-manufacture.com/Labeling-Machine-Labeling-Equipment-p949.html

Feature
1. Adopt original labeling technology to ensure the stability of labeling and positioning accuracy. No
air bubble, no wrinkle, and raise the additional value of products.
2. The frame and shell adopt stainless steel and high class aluminium alloy anodic treatment, the
useful time is long.
3. Adopt famous factory step motor to ensure high load and long period operation.
4. With PLC, clutch and electric eye control, ensure the labeling accuracy, the operation is simple
and convenient, the function is stable.
5. Open frame, adjust the label paper of different sizes and change parts are all convenient.
6. Disconnect - type design for the glue-plate, frictioning knife and glue-wheel, so the cleaning is
very easy.
7. The efficiency is about three to four times than manual operation, reducing labor cost, and
management cost.
8. With the functions of autocorrection and automatic detection when no label.
9. With the functions of fault alarm and production counting.
Specification
1.Label width: 40-200mm
2.Label length:80-380mm
3.Products Diameter:
Diameter : φ30mm-φ120mm
Height : 30mm-230mm
4.Max Labeling speed: 35pcs /min
5.Accuracy of labeling:±1mm
6.Power: 220V/110V 50/60Hz 80W
7.Machine Net Weihgt : 45KG
8.Machine Dimension: 630mm x 430mm x 330 mm
