EMAIL SDMP E Watthour meter Pulse output

R
RODALCO2012

1 Views • Nov 16, 2014

Description

The Email SDMP E meter was connected to a load and pulse output was connected to LED's.
8 Volts DC external power was applied to the common ( white ) wire and the orange wires fed a 1800 R and LED in series.
Internal metering contacts provide an impulse every 0.375 Wh.

Keywords & Tags

#Electricity meter #pulsing #Email #SDMP E #meter #watthour meter #electric #LEDs #compteur #CT meter
