BeanAir - Wireless Triaxial Accelerometer

• Wireless Triaxial accelerometer based on MEMS Technology
• Measurement range: +/- 2g or +/- 10g
• Excellent radio link thanks to the radio antenna diversity developed by Beanair®
• Streaming mode: 5 KHz sampling frequency (mono-channel)
• Radio Range : 30 m to 1000 m (L.O.S)
• Ultra-Power Radio Technology IEEE 802.15.4
• Current consumption in idle mode : less than 45 uA
• Embedded logger : up to 1 000 000 measurements records (with events dating)
• Entirely autonomous system : function either on Lithiumthionyl chloride primary battery or on Lithium-Ion rechargeable battery
• Watertight Aluminium enclosure IP66 (dimensions Lxlxh : 80x55x21 mm—weight 135g rechargeable battery d) - suitable for Harsh Industrial Environment

Applications: Dynamic measurement on embedded equipment, Vibration analysis, Inertial Measuremen, tMovement and Shock detection

www.beanair.com
