Automatic Gloves Pad Printing Machine

http://www.printer-manufacture.com/Four-Color-Pad-Printer-With-Conveyor-p124.html

Feature
1.SCM IC complile action program,kinds of printing model option
2.Auto 4-digit counter built-in,and stat. Printing quantity
3.Airframe adopts coin alloy,and metal coating surface
4.Worktable, printing head and ink tray can be adjusted X.Y.Z direction
5.Sucking ink and the pressure of printing pad can be adjusted independently .
6.Scrapper stroke can be adjusted
7.It has function of leveling ink by sliding automatically on front /back,this can avoid printing ink partial solidification
8.The speed of all the cylinders have an independent regulator intortum
9.Adopts original Japan SMC and Taiwan MINDMAN pneumatic component
10.Each adjustable location has scale logo
11.It has the function of forbiding the pad fallen when no air pressure enter into
12.The machine is running fastly,it is steady and low voice
13.Installing auto quenching system, adjust temperature
Specification
steel plate size: 100*150mm
printing speed: 1500pcs/hr
power: 220V 50-60HZ 30W
air pressure: 5-7bar
transversa distance：160MM
vertical distance：75MM
Max.outside size of products: L200* W90-100MM
Max.printing area：60*120MM
centre distance of ink tray: 127MM
Printing workstation: 16 PCS
Fixuping clamp method：T-slot table, code pressure compress heavily
Net weight : 150Kg
Shape dimension:1250× 950× 1400mm
