Ansys # 6
D
DesignWorld
1 Views • Sep 10, 2022
Description
A reinforced concrete slab floor is shown in the below figure. Using a 0.1m width of the slab in the Z-direction. Determine the deflection curve of the neutral surface under its own weight.
Slab Thickness = 0.1m
Concrete Properties
Young's Modulus, E = 30X10
Poisson's Ratio = 0.21
Density = 2400
Slab Thickness = 0.1m
Concrete Properties
Young's Modulus, E = 30X10
Poisson's Ratio = 0.21
Density = 2400
