Find the deflections at the nodes, bending moment diagram and shear force diagram for a simplified electrical pole with fixtures as shown in the below figure.
Steel:
Young's Modulus, E = 2.1X108 KN/m2
Poisson's Ratio = 0.3
Aluminum:
Young's Modulus, E = 7X107 KN/m2
Poisson's Ratio = 0.33
Steel:
Young's Modulus, E = 2.1X108 KN/m2
Poisson's Ratio = 0.3
Aluminum:
Young's Modulus, E = 7X107 KN/m2
Poisson's Ratio = 0.33
