Aircraft-Station-Numbers

Aircraft Station numbers help to
locate components and reference
points for service, maintenance and
repair of aircraft.

Types:-

#1. Fuselage or
Body Stations

Fuselage or body stations help to locate
longitudinal points along the fuselage of an
aircraft by reference to a zero datum line
(usually at or near the forward portion of
fuselage). Station numbers forward of
datum line are negative (-) and aft of datum
line are positive (+)

#2. Wing
Stations

Wing stations help to locate points
on the wing of an aircraft,
measured right or left from the
center line of fuselage (known as
butt line)

#3. Component
Stations

Component stations help to locate
points on individual components
like aileron, wings, landing gear,
vertical stabilizer, etc. It uses
datum line, butt line as well as
water line.

Table of content:

Topics Time

Aircraft station numbers 00:07
Fuselage station 00:18
Wing station 00:41
Component station 00:56
