Aavega Webbing Ladder Launcher for Building Entry for commandos

The Aavega Webbing Ladder Launcher (AWeLL) System (tactical launcher) confirm the CERTIFICATE OF CONFIRMITY for system standards and specifications be the lightweight, metallic body designed for rugged use in the land and marine environment and user friendly. Physical Characteristics:
1. Weight Approx 7.0 Kgs (Without additional fittings)
2. Length not more than 42 Inches.
3. Capable of launching a grapnel projectile a man fired and platform base fire up to a horizontal distance of min. 100 meters and vertical height of min. 50 meters with a minimum 5 mm climbing rope.
4. Pressure bottle chargeable up to 200 bars.
5. The main system-charged air bottles (200 Bar) can handle at least 3 projectile/ grapnel launches. The Launcher have the following accessories.
1. Three sets of grapnels with associated 03 ropes of appropriate length (110 Meters) to meet the vertical and horizontal ranges mentioned above.
2. Three sets of orange line projectiles with associated 03 ropes of appropriated length (150 Meters) for min. 125 meters horizontal distance with a minimum 3 mm high tenacity rope.
3. Operator and maintenance manual.
4. 01 No. auxiliary Charged air bottle with HP/LP Hoses/ pipes, Adaptors and pressure gauge for air charging of the bottle. The working pressure of 6.8 L auxiliary bottle is 300 Bar and certified by PESO.
5. 01 No. the main cylinder has a capacity of one litre, 200 Bar.
6. Sturdy and reliable carrying arrangement incorporating a tactical design for easy of carrying the launcher and associated equipment. The Storage Box is water proof, wheeled for transportation.
7. Capable of bearing a minimum load of at least 1000 Kgs when grapnel hooked in position. 8. Spare O-ring set: 01 No.
9. Anti corrosive spray: 01 No.
10. Protective Guard for minimize recoil during fire.
