120cm (4ft) Ku-Band Solid Offset Satellite Dish Starter Kit Unboxing

THE HAPPY SATELLITE NERD EPISODE 49
DESCRIPTION
High performance 120cm (48 inch) Ku-Band polar mount, actuator driven, offset solid satellite dish. This large Ku-Band dish is a hobbyists dream!

This dish size will receive 100% of available North American Ku-Band satellite broadcasts and 95% of Latin American Ku-Band satellite broadcasts. If you add our conical scalar ring and C/Ku LNBF, you will also receive about 25% of available C-Band satellite broadcasts, including popular OTA subchannels like TV Decades, Me TV, Movies! and others.

If you are in the USA/Mexico/Carribean and want to pickup Ku-Band signals from Canada, this dish will do it. If you are in the USA or Canada and want to pick up ClaroTV, Dish Mexico or other weak signals from Central/South America, this dish will also do it. If you want access to international programming found on 30°W, 95°W, 97°W and 113°W, this dish will will get it all!

It can be used as a stationary dish or fully motorized with an actuator to track multiple satellites.

Note: This is our 3rd generation model. It is a polar mount dish that requires an 18" or 24" actuator and controller for tracking the satellite arc.

Note: An 18" actuator will track the satellite arc from 50°W to 135°W. A 30" actuator will track the satellite arc from 15°W to 135°W.

Note: Includes pole. Feed, LNBF, conical scalar, actuator and controller sold separately.
FEATURES

Excellent construction with precise offset parabolic geometry
Polar Mount, actuator driven
Rolled edge for extra strength
Includes a standard fit Pole and all hardware for easy installation
Best performing dish for reliable Ku-Band satellite reception
High Ku-Band signal gain

INCLUDES

120cm Offset Reflector Dish
Polar Mount
3 inch diameter/3ft high mounting pole
LNBF holder
Two Actuator Plates
Dual screw declination adjustment
Nuts and bolts
https://rover.ebay.com/rover/1/706-53473-19255-0/1?icep_id=114&ipn=icep&toolid=20004&campid=5338505983&mpre=https%3A%2F%2Fwww.ebay.ca%2Fitm%2F1-2m-48-inch-Ku-Band-Solid-Offset-Satellite-Dish%2F333261403727%3Fhash%3Ditem4d97ed764f%3Ag%3AyZ4AAOSw2PtaqHc4
Specification Value

Antenna Construction
Material Galvanized Steel
Offset Angle 24.6°
Diameter Short Axis 48" (120cm)
Diameter Long Axis 53" (134.6cm)
Performance
Ku_band Gain(@12.2GHz) 43.1dBi (Typ)
Aperture Efficiency 80% (min)
Mounting
Mounting Type Ground and Pole Wall Mount
Adjustment Type Azimuth and Elevation
Elevation Angle Range 5° to 80°
Azimuth Range 0° to 360°
Declination Adjustment 0° to 10°
Pole Diameter 3" (7.6cm)
Pole Height 34" (86.4cm)
Environment
Operational Winds 90km/h
Survival Winds 180km/h
Ambient Temperature -50°C to +60°C
Relative Humidity 0~100%
Shipping Details
Box 1 54"x50"x6" Reflector (30 lbs)
Box 2 40"x8"x8" Polar Mount (35 lbs)
